0.8mmBTB 24P to 140P Female Header H15.7 SMT Gold Plated LCP Reel packing

This product family is a series of Board-to-Board connectors from Jinling Electroincs with a mission to meet all the needs of the industrial market with maximum functionality.

Board-to-board connectors are the most powerful connector products of all connector product types, widely used in power systems, communication networks, financial manufacturing, elevators, industrial automation, medical equipment, office equipment, home appliances, military manufacturing industry etc.
At present, the main spacing of the board-to-board connectors is 0.4mm, 0.5mm, 0.635mm, 0.8mm, 1.00m, etc.

MATERIAL
UL No#
Contact Material	Phosphor Bronze/brass
Insulator Material	PA6T/PA9T/LCP
Contact plating	Au or Sn over 50U"NI
Withstanding Voltage	200V
Current Rating	0.5A
Insulation Resistance	1000MΩ Min
T&R packing :	Reel packing
soldering type	SMT
Operation Temperature:	-40 ℃ to +105 ℃

Features:

High Quality Guaranteed
First Class Service
Best Prices
Stable performance
sturdy and durable
Long lifespan
wear resistant

Advantage:

1. High quality.
2. Competitive price.
3. Fast delivery time.
4. Variety models and specifications.
5. Professional manufacturer.

We are looking forward to long term cooperation with customers, we will make best service and after sales service for all of our customers. If you have any inquiry, please don’t hesitate to contact us. We will reply you at the first time as we can.

Engineering drawing:

3710FXXX157XXXX01.pdfEngineering drawing(female header)
