Green Color 3.5 3.81 3.96 mm Screw Terminal Blocks Female DIP Type

Product description:

Specifications:

Rated Currency:	150V,10A
Dieletric Strength:	AC2000V/1 Minute
Insularion Resistance:	1000mΩ Min
Contact Resistance:	20mΩ Max
Screw Torque:	0.2Nm(1.7Lb.in)
Wire Range:	26~16AWG
Strip Length:	5-6mm
Term. Range:	-40℃~+105℃
Max Solering	+250℃.5S
Housing Material:	PA66(UL94 V-O)
Contact:	Brass, Tin Plating
Clamp:	Brass/Steel, NI Plating
Wire Protector:	Brass,Ni Plating
Screw:	M2.0, Steel, Zinc Plating

JL124D-XXXXXXX1.pdf

Company Information:

Shenzhen Jinling Electronics Co.,Ltd , Which is Global designer and manufacturer of industry standard and custom connectors,was established 2001 and specialized in manufacturing of precision Board to Board, Wire-to-board connectors,sim card socket, terminal blocks and cable assemblies for computer and all kinds of consumer electronics.We always follow the guideline of specialization and automatization since the establishment.

Production Capability:

The factory with area of 20,000 square meters and has about the total number of employees 600 people and owns 30 sets precision mold processing equipment from Taiwan, 34 sets precision plastic injection machine from Taiwan& Japan, as well as 24 sets high –speed precision punch, more than 500 sets various types of plastic molds and more than 240 sets hardware terminal molds,35 sets laboratory testing equipments and over 200 sets machines for automatic assembly that can provide customers with over 10 sorts and 20,000 different specification connectors parts, company handles import-export rights. and up to 40% products are exported to Euro-American countries.

Complete Testing Equipment:

To provide high quality and best performance -to -price ratio production for customers, we have realized integrated production from plastic and hardware terminals, terminals,plating, design and development of mold, precision plastic ejection and molding and high speed precision hardware punching, to the automatic assembly of products.

Certifications:

The company main ten series products obtained American UL & CUL certification, with the No. E362810 and No.E472355, E484895(terminal block). All items are in line with EU RoHS and REACH environmental requirements

FAQ:

Q: What is the MOQ?
A: Our MOQ is: 1000 PCS(1 PCS for sample).

·Shipping

1. If goods is not large:Fedex .DHL.EMS.UPS,TNT,ect express shipping method.

2. If goods is large:Sea or Air shipping method

Company Profile:

Shenzhen Jinling Electronics Co., Ltd. was established in 2004,located in Yusheng Industrial Park, Bao'an District, Shenzhen. The factory area more than 20,000 square meters,currently has 8 production bases, Jinling Electronics is a national high-tech enterprise, with a highly skilled product R&D team and management team, and more than 70 patents for independent product innovation, R&D and production.The company has Taiwan business cooperation exquisite technology,we always adhere to the development policy of specialization and automation,imported complete sets of advanced production and testing equipment from Japan,Germany and Taiwan.We have realized integrated services of R&D and production, from the products development of plastic and hardware terminals,precision plastic injection molding and high-speed precision hardware punching, terminal electroplating and automatic assembly of products.
Our Company has passed: IATF16949 and ISO9001-2015 quality management system certification, ISO14001-2015 environmental management system certification, connector and cable products have passed the United States UL safety certification, UL No.: E362810&E472355, terminal blocks UL NO.: E484895,also have TUV certification and CE certification.Main products include: Pin header&female header,Round pin header&female header , Terminal blocks, Flat cables, FFC flexible cables, Box header&ejector header, Power sockets, SATA, SCSI, DIN41612, PLCC, IDC, BTB connectors, Card Edge connector, SIM card holders etc. series products;more than 60,000 product specifications.Products are widely used in industrial and power control, electronic communications,security,LED photoelectric.liquid crystal displays,inverters, industrial automation, servo systems,Internet of things,medical instruments,automotive electronics,computer motherboards,printers,electronic toys,various kinds of consumer electronics ,electrical appliances and other industries.
We striving to provide customers with high-quality and best-price products.Used scientific management and advanced quality inspection methods to promote continuous updates and iterations of our products,daily production capacity more than 4 million, in order to meet the demand of domestic and foreign markets.
"Splendid Mountains and Rivers,Look to the future”“锦山河，凌未来”Jinling Electronics has"integrity, gratitude, and responsibility"business philosophy,and always adheres to the business policy of "quality first, customer first, excellence, and mutual benefit",Always follow the guideline of our service concept"fast,accurate,thoughtful, careful,meticulous,attentively”,upholding the corporate mission of "creating value for customers, creating profits for the enterprise, and creating happiness for employees", step by step,striding towards the glorious future!

Our business concept:integrity,gratitude and responsibility.

Our business strategy:quality first,customer first,excellence,team work!

Our service philosophy:speed,precise,considerate,carefully,elaborately,diligently.

Our business mission:creating value for customers,creating profits for shareholders,creating happiness for employees.
